Brocade 150-130 Brocade Certified Network Engineer 2012 Exam Practice Test

Demo: 16 questions
Total 113 questions

Brocade Certified Network Engineer 2012 Questions and Answers

Question 1

What are the two ways that IGMP is used? (Choose two.)

Options:

A.

It can be sent by a host to indicate its interest of joining a specific multicast group.

B.

It can be sent among routers to exchange multicast routing information.

C.

It can be used to specify packet forwarding methods for a specific multicast group.

D.

It can be sent by a router to query multicast listeners on a given subnet for all multicast groups.

Question 2

Why would the IP SSH port command be used?

Options:

A.

This command is used to restrict certain port numbers from being used with SSH.

B.

This command is used to change the default port number used by SSH.

C.

This command is required before SSH will respond to any port.

D.

This command is used to set a range of port numbers to be used by SSH.

Question 3

OU need to improve redundancy in your LAN as well as increase bandwidth between switches using a Layer 2 protocol.

Which feature will provide this?

Options:

A.

LLDP

B.

LACP

C.

VRRP

D.

SSTP

Question 4

You have been asked to implement a standards-based Layer 2 loop avoidance protocol with a typical convergence time of 3 seconds or less. Which Layer 2 loop avoidance protocol should you use?

Options:

A.

802.1q

B.

802.1D

C.

MRP

D.

RSTP

Question 5

You have inherited the routing redundancy configuration shown in the exhibit.

Router_A

interface ethernet 1

ip address 192.53.5.1 255.255.255.0

ip vrrp-extended vrid 1

backup priority 110 track-priority 20

ip-address 192.53.5.3

track-port e 14

enable

!

Router_B

interface ethernet 1

ip address 192.53.5.2 255.255.255.0

ip vrrp-extended vrid 1

ip-address 192.53.5.3

track-port e 11

enable

!

Router A is the current VRRP-E master. Your network is not failing over to router B. What needs to be added to configure router B as a backup and maintain the current master?

Options:

A.

backup priority 100 track-priority 20

B.

backup priority 110 track-priority 20

C.

backup priority 120 track-priority 20

D.

backup priority 130 track-priority 20

Question 6

What are two ways that TACACS+ differs from TACACS? (Choose two.)

Options:

A.

TACACS + uses TCP.

B.

TACACS + uses UDP.

C.

TACACS + encrypts traffic between the Brocade device and the server.

D.

TACACS + does not encrypt traffic between the Brocade device and the server

Question 7

What are two functions of an OSPF Autonomous System Boundary Router (ASBR)? (Choose two.)

Options:

A.

The router can run multiple routing protocols.

B.

The router redistributes routes between OSPF areas within an AS.

C.

The router redistributes non-OSPF routes into an OSPF AS.

D.

The router connects one or more OSPF areas to the OSPF backbone.

Question 8

When is an OSPF virtual link used?

Options:

A.

When an area has no direct connection to the backbone area.

B.

When an area needs access to an ASBR.

C.

When an area is configured as a stub area.

D.

When an area needs to connect to a non-backbone area.

Question 9

Two sites 8 km apart will be connected together using fiber optic cable. Which SFP/cable combination needs to be used?

Options:

A.

short reach SFP with multi-mode fiber

B.

short reach SFP with single-mode fiber

C.

long reach SFP with multi-mode fiber

D.

long reach SFP with single-mode fiber

Question 10

You have a LAG configured and are having problems with the logical interface coming online.

What would cause this?

Options:

A.

One end of the LAG is a Brocade FastIron stack.

B.

The LAG members are made up of 1 Gbps and 10 Gbps ports.

C.

The LAG includes members that are not consecutive (ports 1, 2, and 4).

D.

AII members of the LAG are configured as static.

Question 11

What is the minimum cabling requirement for PoE+?

Options:

A.

Category 2

B.

Category 3

C.

Category 4

D.

Category 5

Question 12

Referring to the exhibit,

#show lag

Total number of LAGs: 1

Total number of deployed LAGs: 0

Total number of trunks created:0 (128 available)

LACP System Priority / ID: 1 / 0024.3891.4f00

LACP Long timeout: 90, default: 90

LACP Short timeout: 3, default: 3

=== LAG "30Gig_Trunk" ID 1 (dynamic Not Deployed) ===

LAG Configuration:

Ports: e 1/3 e 1/5 e 1/7

Port Count: 3

Primary Port: 1/3

Trunk Type: hash-based

LACP Key: 100

Which command must be entered to make the LAG function on a

Brocade NetIron MLXe?

Options:

A.

deploy

B.

enable

C.

forward-Iacp

D.

Iacp-cfg-det-dis

Question 13

Referring to the exhibit, an Ethernet frame enters Switch A, port e1 with destination address:

0005.3392.a30d.

What describes how Switch A will process the frame?

Options:

A.

The frame will be sent out port e2.

B.

The frame will be sent out port e3.

C.

The frame will be sent out ports e2 and e3.

D.

The frame will be trapped to the CPU and the destination address changed to 0005.1e00.000c.

Question 14

Which type of transceiver would be used to support a 5 km single mode fiber 10 Gbps connection?

Options:

A.

SFP

B.

SFP+

C.

GBIC

D.

SFM

Question 15

You have just purchased 22 new Brocade FastIron FCXs. You want to take advantage of Brocade IronStack technology to make as many of the FCXs appear as a single stack as possible. What is the minimum number of Brocade IronStacks required?

Options:

A.

1

B.

2

C.

3

D.

5

Question 16

A client had ports 1/3/1 and 1/3/2 on the Brocade FCX go down because of errors being received from the upstream switch. The client repaired the upstream switch but the ports of the FCX are still down.

Referring to the command output shown above, what does the client need to do to bring up the links?

Options:

A.

Enable the ports.

B.

Restart spanning tree.

C.

Restart the routing protocol.

D.

Reseat the cables for each port.

Demo: 16 questions
Total 113 questions
