SNIA S10-210 Storage Networking Management and Administration Exam Practice Test

Demo: 14 questions
Total 97 questions

Storage Networking Management and Administration Questions and Answers

Question 1

You determine that throughput between a server and an FC storage array is lower than expected.

Your privileges only allow you to change the configuration of the HBA on the server.

Which configuration setting can you change to increase throughput?

Options:

A.

Queue length

B.

Queue depth

C.

Topology

D.

Class 1 service

Question 2

Which standard would be used to increase interoperability between solutions of different cloud storage providers?

Options:

A.

SES

B.

CDMI

C.

CWDM

D.

DWDM

Question 3

What is a common protocol used in cloud communications?

Options:

A.

WebDAV

B.

SCP

C.

HTTP

D.

CDMI

Question 4

Which two cloud deployment models address data privacy issues? (Choose two.)

Options:

A.

Community

B.

Public

C.

Private

D.

Hybrid

E.

Campus

Question 5

What is the storage protocol used between initiators and targets connected to an FCoE fabric?

Options:

A.

SATA

B.

SCSI

C.

SAS

D.

FCoE

Question 6

You have two new FC switches from the same vendor and want to connect them together. You have ensured that the domain IDs are unique, switch names are unique, and the firmware levels are identical. When you connect the ISL cables from one switch to the other, the fabric does not merge.

What should be confirmed?

Options:

A.

Ensure the ISL ports are E_Ports.

B.

Ensure the ISL ports are B_Ports.

C.

Ensure the ISL ports are F_Ports.

D.

Ensure the ISL ports are N_Ports.

Question 7

A business critical enterprise resource planning (ERP) system uses a central database at a company's primary data center. The company has built an out-of-region disaster recovery data center and intends to implement a standby ERP system with an eight hour RTO and 30 minute RPO.

Which architectural approach to implement service continuity for the ERP database will meet the RTO and RPO targets?

Options:

A.

Implement asynchronous replication of the ERP database, application, and middle tiers to ensure the ERP system is back online with less than 30 minutes of data loss within eight hours of an event.

B.

Implement asynchronous replication of the ERP database, application, and middle tiers to ensure the ERP system is back online with less than eight hours of data loss within 30 minutes of an event.

C.

Perform daily full database backups to tape and overnight ship the backup tape media from one data center to the other to ensure the ERP system is back online with less than eight hours of data loss within 30 minutes of an event.

D.

Implement synchronous database replication and configure application logic to ensure transactions are identical in both data centers as the recovery objectives do not allow for any inflight data loss.

Question 8

The enterprise storage system has the "call home" feature enabled and configured. However, the storage administrator has been told that "call home" is not working.

Which two actions should you perform? (Choose two.)

Options:

A.

Verify SMTP settings.

B.

Verify SNMP thresholds.

C.

Verify firewall rules.

D.

Verify the SMI-S configuration.

E.

Verify VSAN configuration.

Question 9

You need to merge two existing FC fabrics. After connecting the ISL to join the fabrics, numerous switches segment.

What should be done to prevent the segmentation?

Options:

A.

Physically separate the switches to opposite sides of the data center.

B.

Move business critical applications to clusters.

C.

Increase the frequency of snapshots for critical data.

D.

Assign domain IDs which are unique across both fabrics.

Question 10

You are using asynchronous storage replication to protect your critical database server. There are no replication agents installed on the database server. After a disaster, you are unable to bring up the database at the DR site.

What is the cause?

Options:

A.

The database requires replication from a second storage array.

B.

The database requires synchronous storage replication.

C.

Two copies of databases are required at the DR site to be able to replay transaction logs.

D.

An installed agent is required for the database to be quiesce and replicated in crash-consistent state.

Question 11

You have been asked to implement a remote data replication scheme. The current data center is mostly constructed of FC components and the corporation is highly invested in the technology. The remote data center needs a synchronous replication solution.

What will accomplish this goal?

Options:

A.

iSCSI

B.

NAS

C.

FCIP

D.

FCoE

Question 12

After provisioning a new LUN to a host, new storage cannot be detected on the host. Which three actions should be performed to troubleshoot this problem? (Choose three.)

Options:

A.

Scan memory on a host.

B.

Scan for new storage on the host,

C.

Verify that LUN mapping is correct.

D.

Verify that zoning on the FC switch is correct.

E.

Verify that the size of memory pages and block size is the same.

Question 13

Click the Exhibit button.

Referring to the exhibit, which RAID level is shown?

Options:

A.

RAID 4

B.

RAID 5

C.

RAID 0

D.

RAID 6

Question 14

Your company's Service Level Agreement (SLA) requires that no more then one hour's worth of data be lost in case of a system crash. The data must also be restored within 10 hours.

Which two RTO/RPO combinations meet the SLA? (Choose two.)

Options:

A.

RTO 1 hour, RPO 10 hours

B.

RTO 10 hours, RPO 1 hour

C.

RTO 9 hours, RPO 1 hour

D.

RTO 1 hour, RPO 9 hours

Demo: 14 questions
Total 97 questions
